    Overview
    Quick Details
    CRI (Ra>):
    70
    Beam Angle(°):
    50° 60° 90° TYPE II_S TYPE III_M TYPE IV_S TYPE V
    Working Lifetime(Hour):
    50000
    Lamp Body Material:
    Aluminum
    IP Rating:
    IP66
    Certification:
    ce, RoHS
    Place of Origin:
    Shanghai, China
    Brand Name:
    CHZ
    Model Number:
    CHZ-FL21 -450w
    Application:
    Sports Stadiums
    Light Source:
    LED
    Lamp Luminous Flux(lm):
    65250
    Working Temperature(℃):
    -40 to +50
    Lumen:
    145lm/w
    LED chip:
    smd3030
    CCT:
    4000K/5000K/5700K
    PF:
    PF>0.9
    CRI:
    >70
    Warranty:
    5years
    Input Voltage(V):
    ac100-277V 50/60Hz

    Packaging & Delivery

    Selling Units:
    Single item
    Single package size:
    70X52X21 cm
    Single gross weight:
    13.900 kg
    Lead Time :
    Quantity(Pieces) 1 - 5 6 - 100 101 - 1000 >1000
    Est. Time(days) 7 20 25 To be negotiated
    Product Description

    Free sample 400watt led flood light 400 w 300watt floodlight

    Each module can be ange adjustable flexiblely, so it can be used for more applications.

    Features:

    1. Adjustable projecting direction to get precious aiming;

    2. Beam angle 45°/60° /90° for option, deliver precise circular pattern into certer of sports lighting field from corne high mast, which offers solution especially for soccer/hockey/football field;

    3. Use ultra-high brightness smd3030 chips which can be up to 140lm/w;

    4. Each module can be ange adjustable flexiblely, so it can be used for more applications.

    5. Stainless steel wireguard is designed to protect the fixture from hitting by high-speed objects.

    6. With 10KV surge protection and stainless steel chain for further protection on request.


    Applications:

    Widely used in large space lighting places exhibition center, large warehouses, soccer or football field, indoor stadiums and etc.


    Parameter:

    Model

    FL21-150W

    FL21-220W

    FL21-300W

    FL21-450W

    Power

    150W

    220W

    300W

    450W

    LED type

    SMD 3030

    SMD 3030

    SMD 3030

    SMD 3030

    LED`s

    224PCS

    336PCS

    448PCS

    672PCS

    Connection

    2*(16P7S)

    3*(16P7S)

    2*(32P7S)

    3*(32P7S)

    Chips Volt

    42V

    42V

    42V

    42V

    Lumen(Lm/W)

    >145

    >145

    >145

    >145

    Product size(mm)

    341x286x185

    346x380x227

    613x286x185

    618x384x227

    Model

    FL21-150W

    FL21-220W

    FL21-300W

    FL21-450W

    Power

    150W

    220W

    300W

    450W

    LED type

    SMD 3030

    SMD 3030

    SMD 3030

    SMD 3030

    LED`s

    224PCS

    336PCS

    448PCS

    672PCS

    Connection

    2*(16P7S)

    3*(16P7S)

    2*(32P7S)

    3*(32P7S)

    Chips Volt

    42V

    42V

    42V

    42V

    Input Volt

    100-277V

    control method

    Conventional/0-10V/DALI

    PF

    >0.95

    Lumen(Lm/W)

    >135

    >135

    >135

    >135

    CCT

    4000K/5000K/5700K

    RA

    >80

    Beam angle

    40°/60°/90°, for options

    IP

    IP66

    Product size(mm)

    341x286x185

    346x380x227

    613x286x185

    618x384x227

    Light material

    Die-cast aluminum body + PC lens

    Lamp body color

    Regular black, gray, can be customized according to customer requirements (quantity requirements)

    Protection level

    IP66/IK08/10KV

    Work temp

    —40~+50

    Work humidity

    10%~90%

    Life/Warranty

    50,000hrs / 5Years


    Free sample 400watt led flood light 400 w 300watt floodlight 6Free sample 400watt led flood light 400 w 300watt floodlight 8Free sample 400watt led flood light 400 w 300watt floodlight 10Free sample 400watt led flood light 400 w 300watt floodlight 12Free sample 400watt led flood light 400 w 300watt floodlight 14







    Company Information

    Free sample 400watt led flood light 400 w 300watt floodlight 24

    Our team

    Free sample 400watt led flood light 400 w 300watt floodlight 26 Free sample 400watt led flood light 400 w 300watt floodlight 28





    FAQ:

    1. What are your market reach throughout the regiion?

    Our markets around the world in every corner, we have many years of experience in foreign trade.Our clients are from different countries. And we have branch office in Spain and Nigeria.



    2. Whar are your main products?

    Our main products are led outdoor lightings including led flood light( stadium lighting), led high bay light, led street lighting and led garden light.



    3. Are you a manufactuer or a trading company?

    We are a professional LED manufacturer.



    4. Do you have the ability to do independent research and development?

    Our engineering department have the research and development capabilities. We also collect regular customer feedback to research new product.



    5. How to contact you?

    Welcome to vist our websit (www.chz-lighting.com) to get more information.




    Tasks that are too heavy or too delicate for human muscles to do can be done easily by this product. With high quality LED chips, it can operate for more than 50,000 hours without failure. This piece of clothing will certainly improve the wearer's mood. This is because it will make the wearer feel special. With high quality LED chips, it can operate for more than 50,000 hours without failure.
