Bulk Buy Outdoor Led Flood Lights for Parking Lots

Inquiry

>> CHZ products are designed for the global market. Please contact our sales team for certification details.

>> Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.

Model No.	CHZ-FL42 series
Power	200W, 400W, 600W, 800W, 1000W, 1200W, 1400W, 1600W
Efficacy	>150lm/W or above
Input Voltage	100-240/277 VAC, 50 / 60 Hz
Power Factor	>0.95
Surge Protection	10KV (Default) / 20KV (available on request) with IEC61643-11
IP Rating	IP66
IK Rating	IK08 or IK09
CCT	2200K, 3000K, 4000K, 5000K, 5700K, 6500K
CRI	Ra>70 (Default) / Ra>80
Operating Temperature	-40°C to + 50°C
Beam Angle	30°, 45°, 60°, 90°, TYPE III
Mounting Option	Side entry, or vertical pole mounted with adapters
Warranty	5 Years
Certification/Report	CE, RoHS, ENEC, ENEC+, CB, Zhaga-D4i, LM79, LM80, TM-21, IP66, IK09/IK10, IEC62471/62778, IEC60068-2-6, IEC61643-11, ISO9227, CISPR15:2018
Control	Daylightsensor, DALI Dimmable, NEMA / Zhaga Socket, Motion Sensor, 1-10V Dimmable, Zigbee or LORA control

30°

45°

60°

90°

TYPE III

140°×80°

Bulk Buy Outdoor Led Flood Lights for Parking Lots 25

Specifications FL42

User manual FL42

Bulk Buy Outdoor Led Flood Lights for Parking Lots 27

Bulk Buy Outdoor Led Flood Lights for Parking Lots 28

Bulk Buy Outdoor Led Flood Lights for Parking Lots 29

Bulk Buy Outdoor Led Flood Lights for Parking Lots 30

Bulk Buy Outdoor Led Flood Lights for Parking Lots 31

Bulk Buy Outdoor Led Flood Lights for Parking Lots 32

Frequently Asked Questions

What's customized dimming profile?

The so-called dimming profile refers to a specific timer dimming function. Rural roads and urban roads have different needs for dimming configurations. At the same time, the timer dimming function of lamps can be customized. For example, rural roads usually have fewer people after 10 p.m., and the dimming curve can be maintained at 100% brightness from 18:00 to 22:00, and adjusted to 50% brightness from 22:00 to 06:00; while the situation on urban roads may require delaying the time by 1-2 hours. The dimming curve can be set to maintain 100% brightness from 18:00 to 24:00, and adjust to 50% brightness from 24:00 to 06:00. CHZ can customize such a dimming curve for you, please contact us for more information.

Dali +timer dimming or 0-10V+timer dimming?

Dimming profile uses the dimming function of the lamp. For example, if 0-10V + timer dimming is used, after setting the timer dimming of the lamp, the controller sends a 0-10V dimming signal to the power supply of the lamp, but the power supply will not perform the dimming operation. And if your lamp is configured with Dali + timer dimming, then after setting the timer dimming, the controller sends a Dali dimming signal to the power supply of the lamp, and the power supply can still execute the instructions of the Dali signal. However, it should be noted that the cost of lamps in the latter is often much higher than that in the former. If your budget is limited, it is recommended to choose the former; if your budget is sufficient, it is best to choose the latter.

Which power supplies can be configured with timer dimming function?

Power supply manufacturers such as Inventronics, Osram, Philips, Done, and Meanwell all provide scheduled dimming functions. CHZ recommends using the timed dimming function of Inventronics, because Inventronics is comparable to Philips and Osram in terms of dimming and product quality, and the price is more affordable. If your budget is limited, Dong’s power supply is also a good choice.

FL42 LED flood light is our best seller in stadium lighting. Because of the CE/CB/ENEC/ENEC+/ROHS certified quality, it is well-liked by our clients, distributors and end-users alike.

Beam angles are very important in lighting designs. FL42 LED flood light has a wide range of beam angles to choose from because of our unique lens designs, from conventional angles to 80°*140° and Asymmetrical 60°, allowing flexible lighting design and potential savings on the budget wise.

Speaking of the budget, not only are procurement budgets important, but the following energy bill is also significant for a stadium/facility to operate. Over 150lm/W of SMD 3030/5050 LED chip allows FL42 LED flood light to save 50% energy cost than conventional lighting fixtures, making it environmentally and economically great product.

Related Products

Bulk Buy Outdoor Led Flood Lights for Parking Lots 33

CHZ-FL21A led floodlight for football fields

Bulk Buy Outdoor Led Flood Lights for Parking Lots 34

CHZ-FL22 aluminum led floodlight outdoor with ce rohs

CHZ-FL32 modules assembly stadium led sports floodlights

CHZ-FL38 New arrival LED best stadium lighting

Related Blogs

Bulk Buy Outdoor Led Flood Lights for Parking Lots 37

What are the Basketball Court Lighting Standards?

Flood Light's Buying Guide

Bulk Buy Outdoor Led Flood Lights for Parking Lots 39

How are LED Stadium Lights Beneficial for Green Sports Events?

Why are Football Field Lights Important to a Football Match?

What are the Uses of LED High Mast Lighting?

Bulk Buy Outdoor Led Flood Lights for Parking Lots 42

Brightening the Game: Essential Tips for Football Field Lighting

What is the Illumination & Colour Temperature for Athletic Field Lighting?

Light Up Your Game: The Ultimate Guide to Basketball Court Lighting

Best led high mast light manufacturer, factory, and supplier in China

We are a led high mast light manufacturer, factory, and supplier in China since 2013 and also a high-tech enterprise in Shanghai. The factory is ISO9001, ISO14001, ISO45001, and ISO50001 certified. We are very good at designing, producing, and developing various high-quality road lights.

OEM/ODM is acceptable for us. All the LED high mast light is made of good materials for up to 50,000hrs, ENEC, CB, and CE RoHS certificates. The Photocell, NEMA/ZHAGA socket, smart control, 0-10V, DALI, DALI2, and DC12V-48V low voltage can be available.

Please feel free to consult all questions about high mast lighting projects. We will provide free high mast lighting design, the best products, the best service, and the price you like.

Why choose us as your high mast lights supply in China?

Bulk Buy Outdoor Led Flood Lights for Parking Lots 46

OEM/ODM

Available to do OEM/ODM for all high mast lighting luminaire. No MOQ limits for led high mast lights retailers, wholesalers, and engineering companies.

Bulk Buy Outdoor Led Flood Lights for Parking Lots 47

FAST DELIVERY TIME

As a reliable high mast light supplier, we have stocks of raw materials for flood lights, regular delivery time is 5~7 working days for samples and 20~25 working days for bulk.

Bulk Buy Outdoor Led Flood Lights for Parking Lots 48

BEST QUALITY&PRICE

We use top stable quality led driver and chips like Philips driver and chips for all road lights. Providing 5/7 years warranty at the cheapest price.

Bulk Buy Outdoor Led Flood Lights for Parking Lots 49

CERTIFICATES

Our smart high mast light are ENEC, ENEC+, CB, CE, RoHS, IECEE, SAA, and ETL approved, and our factory ISO9001, ISO14001, ISO45001, and ISO50001 certified.

Certification Show

As a professional manufacturer of led high mast light luminaire, our flood luminaires have rich certification and test reports, such as ENEC, ENEC+, CE, CB, ROHS, IEC62471, LM80, LM79, and so on

ISO9001

ISO14001

ISO45001

ISO50001

ENEC

ENEC+

CCC

ETL

SAA

COMPONENT	STANDARDS	TEST REPORT	CERTIFICATIONS
LED chips	LM80	✔
SMD2835SMD3030SMD5050SMD3535SMD3737	EN/IEC 60598-1 y 60598-2-3	✔	✔
	IEC 62471	✔
	EN/IEC 60529	✔
	EN/IEC 62262	✔
	EN/IEC 60068-2-75	✔
	EN/IEC 55015	✔	✔
	EN/IEC 61000-3-2	✔	✔
	EN 61547	✔	✔
	EN 61000-3-3	✔	✔
	LM79	✔
	ISTMT	✔
	TM-21	✔
	LM82	✔
	LM84	✔
	ISO9007 /ASTM B117	✔
	IEC 60068-2-6/ANSI C136.31	✔
LED MODULE	EN/IEC 62031	✔
LED DRIVER	IEC 62384,IEC 61347-1,IEC 61347-2-13	✔	✔
SPD	EN/IEC 61643-11	✔	✔
FACTORY	ISO9001,ISO14001,ISO50001,ISO45001		✔

R & D Team

研发图片 (1).png

研发图片 (6).png

研发图片 (7).png

研发图片 (2).png

研发图片 (4).png

研发图片 (5).png

Product Testing

In order to ensure the high quality of each product, we will conduct more than 30 different aspects of testing in our own laboratory before the product goes on the market. After all the tests are passed, the product can be approved for marketing. In mass production, for some basic safety and performance tests, we will conduct 100% testing to ensure that every product delivered to the customer is perfect.





Production Process

生产图片 (3).png

生产图片 (2).png

生产图片 (1).png

生产图片 (6).png

生产图片 (5).png

生产图片 (4).png

Company Advantages

· The quality and safety of all the materials used for CHZ Lighting outdoor led flood lights are extremely important.

· Strict rules in quality inspections has been set up for this product.

· Shanghai CHZ Lighting Co.,Ltd provides formidable strengths to its customers.

Company Features

· Shanghai CHZ Lighting Co.,Ltd is currently expanding the outdoor led flood lights business quickly in China and foreign countries.

· Relying on strict quality control system and excellent product quality, our outdoor led flood lights has become more and more competitive in this field.

· Long-term and stable business cooperations and high customer satisfaction are what we always pursue after. This objective makes us always focus on offering innovative products and different kinds of product solutions for clients.

Application of the Product

The outdoor led flood lights of CHZ Lighting can meet the different needs of different customers.

CHZ Lighting provides comprehensive and reasonable solutions based on customer's specific situations and needs.

Product Description

A. Special fifin-type heat dissipation, high-purity aluminum stamping and forming, rapid heat

dissipation,

B. Light weight lamp body design, compact structure, light weight, easy to install and maintain, safe and durable.

C. Using high-quality SMD3030 LED light source chip, and AC driver(driverless), to reach high

performance-cost ratio.

D. Balance the internal and external pressure difffference, to provent the condensation in cavity and improve the waterproof effffect.

E. Equipped with a high-precision dial bracket, which supports 2.5° precise adjustment to achieve more accurate projecting.

Bulk Buy Outdoor Led Flood Lights for Parking Lots 79

Bulk Buy Outdoor Led Flood Lights for Parking Lots 80

Bulk Buy Outdoor Led Flood Lights for Parking Lots 81

Bulk Buy Outdoor Led Flood Lights for Parking Lots 82

Bulk Buy Outdoor Led Flood Lights for Parking Lots 83

Bulk Buy Outdoor Led Flood Lights for Parking Lots 84

Bulk Buy Outdoor Led Flood Lights for Parking Lots 85

Bulk Buy Outdoor Led Flood Lights for Parking Lots 86

Bulk Buy Outdoor Led Flood Lights for Parking Lots 87

Applications

Widely used in construction sites, docks; basketball courts, football fields, indoor stadiums; squares, parking lots, crossroads; buildings, bridges, factories and other lighting places

Bulk Buy Outdoor Led Flood Lights for Parking Lots 88

Model No.	Power(W)	Chips	Chips Qty	Chips S/P	Lumen(Lm/W)	Size(L×W×H)mm
FL42-200W	200W	SMD3030	224	28P8S	>140	490×150×141
FL42-400W	400W	SMD3030	448	28P8S	>140	490×315×154
FL42-600W	600W	SMD3030	672	28P8S	>140	490×428×154
FL42-800W	800W	SMD3030	896	28P8S	>140	490×554×154
FL42-1000W	1000W	SMD3030	1120	28P8S	>140	490×667×154
FL42-1200W	1200W	SMD3030	1344	28P8S	>140	520×776×154
FL42-1400W	1400W	SMD3030	1568	28P8S	>140	520×889×154
FL42-1600W	1600W	SMD3030	1792	28P8S	>140	520×1002×154
FL42-200W	200W	SMD5050	88	44P2S	>150	490×150×141
FL42-400W	400W	SMD5050	176	44P2S	>150	490×315×154
FL42-600W	600W	SMD5050	264	44P2S	>150	490×428×154
FL42-800W	800W	SMD5050	352	44P2S	>150	490×554×154
FL42-1000W	1000W	SMD5050	440	44P2S	>150	490×667×154
FL42-1200W	1200W	SMD5050	528	44P2S	>150	520×776×154
FL42-1400W	1400W	SMD5050	616	44P2S	>150	520×889×154
FL42-1600W	1600W	SMD5050	704	44P2S	>150	520×1002×154

Details

Bulk Buy Outdoor Led Flood Lights for Parking Lots 89

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
