Model No.	CHZ-FL21 series
Power	75W, 150W, 220W, 300W, 450W, 600W
Efficacy	>135lm/W or above
Input Voltage	100-240/277 VAC, 50 / 60 Hz
Power Factor	>0.95
Surge Protection	10KV (Default) / 20KV (available on request) with IEC61643-11
IP Rating	IP66
IK Rating	IK08 or IK09
CCT	2200K, 3000K, 4000K, 5000K, 5700K, 6500K
CRI	Ra>70 (Default) / Ra>80
Operating Temperature	-40°C to + 50°C
Beam Angle	40°, 60°, 90°
Mounting Option	Side entry, or vertical pole mounted with adapters
Warranty	5 Years
Certification/Report	CE, RoHS, ENEC, ENEC+, CB, Zhaga-D4i, LM79, LM80, TM-21, IP66, IK09/IK10, IEC62471/62778, IEC60068-2-6, IEC61643-11, ISO9227, CISPR15:2018
Control	Daylightsensor, DALI Dimmable, NEMA / Zhaga Socket, Motion Sensor, 1-10V Dimmable, Zigbee or LORA control


60°

90°

Outdoor Led Garden Lights High Mast Lighting Wholesale - CHZ Lighting 22

Specifications FL21

User manual FL21

Outdoor Led Garden Lights High Mast Lighting Wholesale - CHZ Lighting 24

Outdoor Led Garden Lights High Mast Lighting Wholesale - CHZ Lighting 25

Outdoor Led Garden Lights High Mast Lighting Wholesale - CHZ Lighting 26

Outdoor Led Garden Lights High Mast Lighting Wholesale - CHZ Lighting 27

Outdoor Led Garden Lights High Mast Lighting Wholesale - CHZ Lighting 28

Outdoor Led Garden Lights High Mast Lighting Wholesale - CHZ Lighting 29

Frequently Asked Questions

What's customized dimming profile?

The so-called dimming profile refers to a specific timer dimming function. Rural roads and urban roads have different needs for dimming configurations. At the same time, the timer dimming function of lamps can be customized. For example, rural roads usually have fewer people after 10 p.m., and the dimming curve can be maintained at 100% brightness from 18:00 to 22:00, and adjusted to 50% brightness from 22:00 to 06:00; while the situation on urban roads may require delaying the time by 1-2 hours. The dimming curve can be set to maintain 100% brightness from 18:00 to 24:00, and adjust to 50% brightness from 24:00 to 06:00. CHZ can customize such a dimming curve for you, please contact us for more information.

Dali +timer dimming or 0-10V+timer dimming?

Dimming profile uses the dimming function of the lamp. For example, if 0-10V + timer dimming is used, after setting the timer dimming of the lamp, the controller sends a 0-10V dimming signal to the power supply of the lamp, but the power supply will not perform the dimming operation. And if your lamp is configured with Dali + timer dimming, then after setting the timer dimming, the controller sends a Dali dimming signal to the power supply of the lamp, and the power supply can still execute the instructions of the Dali signal. However, it should be noted that the cost of lamps in the latter is often much higher than that in the former. If your budget is limited, it is recommended to choose the former; if your budget is sufficient, it is best to choose the latter.

Which power supplies can be configured with timer dimming function?

Power supply manufacturers such as Inventronics, Osram, Philips, Done, and Meanwell all provide scheduled dimming functions. CHZ recommends using the timed dimming function of Inventronics, because Inventronics is comparable to Philips and Osram in terms of dimming and product quality, and the price is more affordable. If your budget is limited, Dong’s power supply is also a good choice.

FL21 IP66 waterproof 100000 lumen 1200w led floodlight outdoor is a classical LED stadium light, it features high build quality and long lifespan while being versitile in a lot of situations. Having the option of different beam angles from 50°-90°, also type II/type III/type IV/type V, FL21 IP66 waterproof 100000 lumen 1200w led floodlight outdoor will be the perfect light for large area lighting.

Another selling point of the FL21 series is the angle-adjustable module. So from area lighting to sport complexes, the FL21 will handle it just fine. And with the lumen efficiency up to over 145 lm/W, and the power range of 150-600W, it is perfect for fields like basketball/tennis/table tennis and recreational areas.

Using LED Light rather than conventional lighting means not only energy saving, but also low maintenance cost. The FL21's LED chip has a lifespan of 50000 hours, and with our 5-year warranty, it's definitly a good choice for your projects.
